Applicable syringes :
|
10ml,20ml,30ml,50ml,60ml of any standard
|
|
Accuracy :
|
+/- 2% with correct calibration
|
|
Rate mode :
|
50ml(60ml)：0.1ml/h-1800.0ml/h (0.1ml/h step)
20ml(30ml)：0.1ml/h-800.0ml/h (0.1ml/h step) 5ml,10ml：0.1ml/h-400.0ml/h (0.1ml/h step) |
|
Time Mode :
|
SOL. VOL:0.1-999.9ml (0.1ml step)
TIME：1-1999min (1min step) |
|
Body Weight Mode :
|
Volume：0.1-999.9ml(0.1ml step)
DRUG MASS：0.1-999.9mg(0.1mg step) DOSE：0.01-99.99ug/kg/min(0.01ug/kg/min step) WEIGHT：0.1-300kg(0.1kg the least step) |
|
Total Volume Range :
|
0.1-1999.9ml (0.1 ml step)
|
|
Purge Rate :
|
50ml(60ml)：1800.0ml/h,
20ml(30ml)：800.0ml/h,
10ml：400.0ml/h，5ml: 200ml/h
|
|
KVO Rate :
|
1ml/h
|
|
Occlusion pressure :
|
Three level setting LOW, MEDIUM or HIGH
|
|
Alarms :
|
Near empty, Syringe empty, Volume complete (when limit volume is set), Occlusion, Syringe loose, Operation error, Low battery, device failures.
Three levels of alarm volume LOW, MEDIUM or HIGH
|
|
Bolus Rate :
|
10ml:10-300ml/h,20ml(30ml):10-600ml/h,
50ml(60ml):10-1200ml/h
|
|
Bolus Volume :
|
Maximum of 25ml
|
|
Interface :
|
RS-232
|
|
Power source :
|
AC power supply: AC 100 to 240V( +/-10%)，50/60Hz;
Built-in Lithium Battery: Rechargeable, 11.1V, 2000mAh. 6 hours of continuous operation.
|
|
Accessories :
|
AC power line, Operational manual
|
|
Protection Class:
|
Class I, Type CF,IPX4
|
|
Dimension :
Net weight :
|
280mm*160mm*130mm
2.5kg
|
