• Temperature controlling technology: Adopts intellectual microcomputor controlling technology ,quickly
warm up deuice with high capacity, control the temperature accurately in the predetermined temperature,
and own intellectual detection, safe and reliable.
• Large LCD display: real-time liquid temperature, set temperature, room temperature, dropping speed
(10-300 drips/ min), warming time, alarm indication, electricity on or off indication, liquid exist or not
indication.
• Warming mode
Mode 1: 1-3L/H; Mode 2: 3-4L/H Mode 3: 4-5L/H Mode 4: 5-6L/H
Mode 5: 6-9L/H Mode 6: 9-12L/H Mode 7: ≥12L/H
• VAW-1020C: at the basis of of VAW-1020B,add 2 warmers ,warming speed is 0-15L/H
Security Features
• Low temperature alarm: After working five minutes with the set temperature, if the warming plate's
temperature is lower than the set temperature, the alarm lights flashes with the regular alarm sound,
showing the alarm information (CAN'T BE HEATED).
• High temperature alarm: When the liquid temperature is higher than the limit temperature, the alarm is
triggered,at this time, high temperature warning lights are on with alarm sound, showing the information
(OVERHEAT-LIQUID).The apparatus will automatically stop warming.
• Infrared detectection: Sound alarm of finishing infusoon.
• RS-232 port for computer control centre.
Specification
Power supply: AC 220V±10% 50Hz±1Hz
110V±10% 60Hz±1Hz Power: ≤300W
Temperature range：28℃-36℃（increasing by 0.1℃）
82°F-97°F（increasing by 0.2°F ）±0.5℃ （±1°F)
Outer dimension：190mm×260mm×150mm Weight: 2.5kg
Waterproof and dustproof class: Ip64
